SM01P 30
NO. PARAMETER NAME RANGE OF ADJUSTMENT
FACTORY
DEFAULT
30 SLIP COMPENSATION 0.0 - 5.0 % 0.00 %
31-37 PRESET SPEEDS 0.0 - MAXIMUM FREQUENCY 0.0 Hz
38 SKIP BANDWIDTH 0.0 - 10.0 Hz 0.0 Hz
39 SPEED SCALING 0.0 - 6500.0 0.0
42 ACCEL/DECEL #2 0.1 - 3600.0 SEC 20.0 SEC
44 PASSWORD 000 - 999 225
45 SPEED AT MIN SIGNAL MINIMUM FREQUENCY - 999Hz 0.0Hz
46 SPEED AT MAX SIGNAL MINIMUM FREQUENCY - 999Hz
SCL = 50 Hz
SCM = 60 Hz
47 CLEAR HISTORY MAINTAIN (01), CLEAR (02) MAINTAIN (01)
48 PROGRAM SELECTION
USER SETTINGS (01)
OEM SETTINGS (02)
RESET OEM (03), RESET 60 (04)
RESET 50 (05), TRANSLATE (06)
SCL = RESET
50 (05)
SCM = RESET
60 (04)
50 FAULT HISTORY (VIEW-ONLY) (N/A)
51 SOFTWARE CODE (VIEW-ONLY) (N/A)
52 DC BUS VOLTAGE (VIEW-ONLY) (N/A)
53 MOTOR VOLTAGE (VIEW-ONLY) (N/A)
54 LOAD (VIEW-ONLY) (N/A)
55 0-10 VDC INPUT (VIEW-ONLY) (N/A)
56 4-20 mA INPUT (VIEW-ONLY) (N/A)
57 TB STRIP STATUS (VIEW-ONLY) (N/A)
58 KEYPAD STATUS (VIEW-ONLY) (N/A)
