3 SM01P
INSTALLATION
Ensure proper handling and avoid excessive mechanical stress. Do not bend any
components and do not change any insulation distances during transport, handling,
installation or maintenance.
Do not touch any electronic components or contacts. This drive contains electrostatically
sensitive components, which can easily be damaged by inappropriate handling. Static
control precautions must be adhered to during installation, testing, servicing and repairing
of this drive and associated options. Component damage may result if proper procedures
are not followed.
This drive has been tested by Underwriters Laboratory (UL) and is an approved component
in compliance with UL508C Safety Standard.
Warnings!
• Suitable for use on a circuit as described in Section 7.0 of this manual.
• Use minimum 75°C copper wire only.
• Shall be installed in a Pollution Degree 2 macro-environment.
This drive must be installed and configured in accordance with both national and international
standards. Local codes and regulations take precedence over recommendations provided
in this and other Lenze AC Tech documentation.
The drive is considered a component for integration into a machine or process. It is neither
a machine nor a device ready for use in accordance with European directives (reference
machinery directive and electromagnetic compatibility directive). It is the responsibility of
the end user to ensure that the machine meets the applicable standards.
ELECTRICAL CONNECTION
When working on live drive controllers, applicable national safety regulations must be
observed. The electrical installation must be carried out according to the appropriate
regulations (e.g. cable cross-sections, fuses, protective earth [PE] connection). While
this document does make recommendations in regards to these items, national and local
codes must be adhered to.
The documentation contains information about installation in compliance with EMC
(shielding, grounding, filters and cables). These notes must also be observed for CE-
marked controllers. The manufacturer of the system or machine is responsible for
compliance with the required limit values demanded by EMC legislation.
APPLICATION
The drive must not be used as a safety device for machines where there is a risk of
personal injury or material damage. Emergency Stops, over-speed protection, acceleration
and deceleration limits, etc must be made by other devices to ensure operation under
all conditions.
