4.2 Dumb mode
Figure 5 shows the process for a LSR116 in Dumb mode.
Figure 5. Dumb mode process flow
4.2.1 Dumb mode example
Comments
LSR Command to Host
Host Command to LSR
Media placed in front of
LSR116.
-
-
Imager activated and
barcode scanned.
Illumination activated as
defined in the settings.
Data sent as configured (USB/Serial)
-
No media detected for 0.5
seconds; LSR116 resets.
-
-
Media Detected
Imager and
Illumination
Activated
Barcode Read
Data Sent to Host
Lights ‘Good
Read’ (as Settings
Instruct)
Reader Idle
Imager and
Illumination
Deactivated
Reader Idle
