Access Interfacing Solutions LSR110 - Technical Specifications; Part Numbers and Accessories

Page 5 of 33 Copyright © Access-IS 2020
2. Specifications
Specification
Details
Dimensions (L x H x W)
109.8 mm x 67.4 mm x 105.9 mm
Weight
467 g (with cable)
Environmental
Operating temperature: -25ºC to 50ºC
Storage temperature: -30ºC to 70ºC
Humidity: 95% RH, non-condensing
IP67
Body
Black PC/ABS
Glass
4 mm Toughened White Soda Lime; BS EN60068-2-75 & IEC
62262:2002, rated to 3.5 J impact
Power requirements
5 V DC
Electrical interface
Serial (RS232C) and 5 V USB
Barcode reading
Linear: Code 2 of 5, Interleaved 2 of 5, EAN13, Code 3 of 9,
Code 128 (plus others)
2D: PDF417, QR, Aztec, DataMatrix, (plus others)
Media supported
Reads barcodes from mobile phones, tablets and paper
MTBF
85,000 hours
Approvals
CE EMC Class B
• EN 55022
• EN 55024
CE Low Voltage Directive
• EN 60950-1
• IEC 62471: 2006 - Exempt Class
FCC 47CFR Part 15 Subpart B Class A
2.1 Part numbers
Product
Part Number
Serial connected LSR116
LSR116-S-XX
USB power injector cable
5KBD1334
USB connected LSR116
LSR116-U-XX
Serial cable
5KBD3262
USB cable
5KBD3263
Power supply*
PSU5V3A-VI
* External power supply supplied with LSR116-S-PSU
Power supply complies with LPS and rated: 5V, 500mA
For additional options, please contact the Access IS sales team: sales@access-is.com.
