3 - On (Phone optimised)
Adaptive illumination is on. The illumination LEDs switch ‘Off’ and ‘On’ continuously when you
present media to the device. The LEDs cycle ‘Off’ and ‘On’ until the device reads the barcode or you
remove the media. Use the illumination commands in Table 4 to set the ‘Off’ and ‘On’ time.
5.4 Indicator control
These commands control the behaviour of the ‘Good Read’ and ‘Bad Read’ LEDs.
Table 5. Indicator LED commands
Command
Description
Default
Parameters/Range
AISGDT
‘Good Read’ LED indicator duration.
Each unit is equivalent to 100
milliseconds.
5
0–200
AISGDS
‘Good Read’ duration start.
Specifies when the ‘Good Read’
indicator illuminates.
0
0 - At ‘Good Read’
1 - At media removal
AISGIN
‘Good Read’ indication stop.
Specifies when the ‘Good Read’
indicator extinguishes.
1
0 - At media removal
1 - Continues after media
removal
AISBDT
‘Bad Read’ LED indicator duration.
Each unit is equivalent to 100
milliseconds.
8
0–200
AISBDS
‘Bad Read’ duration start.
Specifies when the ‘Bad Read’ indicator
illuminates.
0
0 - At ‘Bad Read’
1 - At media removal
AISBIN
‘Bad Read’ indication stop.
Specifies when the ‘Bad Read’ indicator
extinguishes.
1
0 - At media removal
1 - Continues after media
removal
AISGSL
Switches between LED locations for the
‘Good Read’ indicator.
5
0 - No lights
1 - Board green lights
2 - Board red lights
4 - Lid green lights
5 - Lid and board green
lights
8 - Lid red lights
10 - Lid and board red
lights
AISBSL
Switches between LED locations for the
‘Bad Read’ indicator.
10
0 - No lights
1 - Board green lights
2 - Board red lights
4 - Lid green lights
5 - Lid and board green
lights
8 - Lid red lights
10 - Lid and board red
lights
