5. Command reference
Commands are sent with a prefix of [0x16][0x4D][0x0D] causing the command sequence to
take the form [0x16][0x4D][0x0D]<Menu Command>. The menu commands are six characters
long with a parameter (if required).
To send a command to modify a configuration parameter
Send the six-character command concluded by a dot ‘.’ or an exclamation mark ‘!’. The dot stores
the setting permanently and the exclamation mark keeps it temporarily until power is removed from
the device.
For example, [0x16][0x4D][0x0D]AISKBL1.sets the keyboard localisation to United States
when the device is operating as a USB keyboard.
To query the current settings (including a temporary one)
Send the six-character command with a ‘?’ instead of the parameter and the LSR116 will return the
command with the current setting. Note the ‘?’ must be followed with ‘.’
For example, [0x16][0x4D][0x0D] AISINF?. queries the device interface and returns the
current value.
To query the stored value
Send the six-character command with a ’^’ instead of the parameter and the LSR116 will return the
command with the stored setting. Note the ‘^’ must be followed with ‘.’
For example, [0x16][0x4D][0x0D] AISINF^. returns the current illumination mode.
To list parameter options
Send the six-character command with a ‘*’ instead of the parameter and the LSR116 will return the
command with the parameter options. Note the ‘*’ must be followed with ‘.’
5.1 Basic configuration
These commands set the device interface, connection parameters and specify the operating mode.
Table 2. Basic configuration commands
Selects the device interface.
When a Serial cable is used, the
configuration is overruled and AISINF0
is used.
When a USB cable is used, the
configuration AISINF0 is overruled and
AISINF1 is used.
