Command
Description
Default
Parameters/Range
PRECA2
Clears all prefixes.
-
-
SUFBK299xx
Adds a suffix to all barcode
symbologies.
Any two-character hex ASCII code can
replace xx.
You can add more than one suffix, as
required.
For example, to add CR (Carriage
Return) and ETX (End of Text) as a
suffix, use the command
SUFBK2990D03.
-
xx - Hex value
SUFCA2
Clears all suffixes.
-
-
5.3 LSR116 illumination
The standard method of reading barcodes cycles the illumination on and off. You can control
illumination for various different applications using the commands in Table 4. For example, it is often
beneficial to turn off the illumination to prevent reflections from shiny surfaces, for example, mobile
phones.
Table 4. Illumination commands
Command
Description
Default
Parameters/Range
AISILL
Adaptive illumination mode (see page
20).
2
0 - Off (Phone only)
1 - Off (Paper only)
2 - On (Paper optimised)
3 - On (Phone optimised)
AISONT
Illumination on time.
Applies to AISILL modes 2 and 3 only
(adaptive illumination on).
Each unit is equivalent to 100
milliseconds.
8
0–200
AISOFT
Illumination off time.
Applies to AISILL modes 2 and 3 only
(adaptive illumination on).
Each unit is equivalent to 100
milliseconds.
8
0–200
AISONM
Illumination on mode.
When set to 0, the timing for the
illumination on period is set to a single
value, AISONT.
When set to 1, the illumination on period
cycles continuously (while triggered)
through the three AISONx values.
0
0 - Normal adaptive
operation; uses AISONT
timing
1 - Cycles through
AISON1 to AISON3
timings
AISON1
Illumination on time 1.
Applies to AISILL modes 2 and 3 only
(adaptive illumination on).
Each unit is equivalent to 100
milliseconds.
1
0–200
