4.3.1 Host mode example
4.3.1.1 Accept
Comments
LSR Command to Host
Host Command to LSR
Media placed in front of
LSR116.
-
-
Imager activated and
barcode scanned.
Illumination activated as
defined in the settings.
Data sent as configured (USB/Serial)
-
Host decides to accept or
reject the data.
-
‘Good Read’:
AISXXR0
Lights activated as defined
in the ‘Good Read’ settings.
-
-
No media detected for 0.5
seconds; LSR116 resets.
-
-
4.3.1.2 Reject
Comments
LSR Command to Host
Host Command to LSR
Media placed in front of
LSR116.
-
-
Imager activated and
barcode scanned.
Illumination activated as
defined in the settings.
Data sent as configured (USB/Serial)
-
Host decides to accept or
reject the data.
-
‘Bad Read’:
AISXXR1
Lights activated as defined
in the ‘Bad Read’ settings.
-
-
No media detected for 0.5
seconds; LSR116 resets.
-
-
4.3.1.3 Ignore
Comments
LSR Command to Host
Host Command to LSR
Media placed in front of
LTR116.
-
-
Imager activated and
barcode scanned.
Illumination activated as
defined in the settings.
Data sent as configured (USB/Serial)
-
Host decides to accept or
reject the data.
-
‘Ignore and Continue’:
AISXXR2
No media detected for 0.5
seconds; LTR116 resets.
-
-
