5.5.2 Status LED
The LSR116 contains two small orange LEDs on the main circuit board, typically used for debug
purposes only. We recommend turning these off in normal use.
A typical configuration will have these turned off, but the default values will be as below (for
example, when using the AISRDS command).
Note: You can combine more than one function by adding the function numbers together. For
example, Brownout status and Intelli sensor reset is 48 + 64 = 112.
Table 7. Status LED commands
Command
Description
Default
Parameters/Range
AISLS1
Status LED function.
4
0 - None
1 - Power on
2 - Loader
3 - Power on and loader
4 - Power on except when
triggered
16 - Brownout detection
(Diagnostic)
32 - Brownout reset
(Diagnostic)
48 - Brownout status -
Detection or reset
(Diagnostic)
64 - Intelli sensor reset
(Diagnostic)
128 - Watchdog reset
(Diagnostic)
AISLS2
Status LED function.
2
0 - None
1 - Power on
2 - Loader
3 - Power on and loader
4 - Power on except when
triggered
16 - Brownout detection
(Diagnostic)
32 - Brownout reset
(Diagnostic)
48 - Brownout status -
Detection or reset
(Diagnostic)
64 - Intelli sensor reset
(Diagnostic)
128 - Watchdog reset
(Diagnostic)
