Introduction
1
Display window
S button
Press this button to change settings.
Recess for docking the lancing device
Test button
Use this button only if you want to test your blood glucose or
perform a control test, or wish to turn the meter off. Pull the button
downwards towards the drum compartment cover. The button tips
downwards and the meter turns on. This pull-tip mechanism stops
the meter from turning on inadvertently.
Drum compartment
Drum release button
Test strip guide
Measuring window
Test strip
Test strip drum
Drum compartment cover*
M Button
Press this button to retrieve results stored in the meter’s memory.
* available as replacement part
