Accu-Chek Compact Plus User Manual

74
Testing blood glucose
Farbe: P 249 – Prüfmittelnummer: 203
4.2.2 Docking the lancing device onto the meter
 Hold the meter so it is horizontal, with the recess for docking the
lancing device pointing upwards.
 Place the flat face of the lancing device on the lower end of the
recess, with the plunger facing towards the slide button.
 Slide the lancing device forward along the meter in the direction
indicated by the arrow, until it locks with an audible CLICK. The
guides along the inside of the recess must engage with the grooves
along the lancing device.
man_06919570001_01_EnCan.indd 74 18.01.2013 18:38:21

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
