Accu-Chek Compact Plus User Manual

21
Initial steps before testing
2
2.2.1 Type plate
The type plate on the back of your meter indicates which unit of
measurement your meter uses.
2.2.2 Display check
You can check the unit of measurement your meter uses by performing
a display check.
 Press and hold down the M button.
The meter turns on. While you hold down the M button, you first see the
display check.
mmol/L meter or mg/dL meter
The unit of measurement is shown in the bottom right corner of the
display.
man_06919570001_01_EnCan.indd 21 18.01.2013 18:37:59

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
