Accu-Chek Compact Plus User Manual

173
Symbols, error messages and troubleshooting
12
Symbol Meaning

Only in a new meter that has not yet been
used to perform tests: There is no test
strip drum in the meter or the mock drum
has been left inserted. Insert a new test
strip drum (see Chapter 2.3).
7
This result is a control test result.
See under Combinations of symbols
8
After testing: You have turned on the hypo
indicator and the displayed result is below
the level you set.
You are in the hypo indicator setting.
In memory: The result is below the limit
that was set at the time of testing.
man_06919570001_01_EnCan.indd 173 18.01.2013 18:39:00

Accu-Chek Compact Plus Specifications

General

Measurement Range	10-600 mg/dL
Sample Size	1.5 µL
Test Time	5 seconds
Automatic Coding	Yes
Display	LCD
Measurement Method	Electrochemical
Battery Type	2 x AAA
Battery Life	Approx. 1000 tests
Data Transfer	Infrared (IR)
Storage Conditions	-25°C to +70°C
Operating Conditions	10-40°C, 10-90% RH
