Accu-Chek Nano User Manual

58
1. Press and release
to turn on the meter.
The flashing test strip
symbol appears on
the display.
2. Press and hold
until set-up appears
on the display.
3. Press and release
repeatedly until
set-up, and the
flashing 1Hr or 2Hr
appear.
4. Press and release
or to select
1Hr or 2Hr. Press and
release
to set the
option.
This display appears
when a post‑meal test
reminder occurs.

Accu-Chek Nano Specifications

General

Display Type	LCD
Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	500 results
Automatic Power Off	Yes
Memory	500 results
Dimensions	69 x 43 x 20 mm
Weight	40 g with batteries
Measuring Range	0.6 - 33.3 mmol/L
Operating Conditions	10 - 90% relative humidity
