Accu-Chek Nano User Manual

34
Changing the Lancet Drum
When you have used the sixth and last lancet, you should change the drum.
1. Take the black cap o the lancing device by
pulling it straight o. It is not a twist cap. The
easiest way to do this is to place your thumb to
the side of the notch as seen in the illustration.
2. Hold the drum between your thumb and index
finger and pull it straight out of the lancing
device. A red stripe is visible on the white part,
indicating that the drum has been used.
NOTE
A used drum cannot be reinserted into the lancing device.

Accu-Chek Nano Specifications

General

Display Type	LCD
Sample Size	0.6 µL
Test Time	5 seconds
Memory Capacity	500 results
Automatic Power Off	Yes
Memory	500 results
Dimensions	69 x 43 x 20 mm
Weight	40 g with batteries
Measuring Range	0.6 - 33.3 mmol/L
Operating Conditions	10 - 90% relative humidity
