5.2 Flipping the Rubber Tongue
When should the rubber tongue be ipped?
The rubber tongue should be ipped when the bill thickness adjustment screw
does not solve the problem of improper banknote feeding or miscounting error
repeatedly.
Procedure: Press the hopper plate (metal plate) downward (gure 1). While
pressing the hopper plate down, push back and remove the rubber tongue lo-
cated underneath the hopper plate (gure 2).
28
5.0 Maintenance cont.
