2-14-10 SHIN-ISHIKAWA, AOBA-KU, YOKOHAMA, JAPAN
ACCUPHASE LABORATORY INC.
0801
Printed in Japan
SPECIFICATIONS
[Guaranteed specifications are measured according to EIA standard RS-490.]
Total Harmonic Distortion
Stereo operation (both channels driven)
0.05
％
with 2 ohm load
0.03
％
with4to16ohmload
Monophonic operation (bridged connection)
0.03
％
with4to16ohmload
Intermodulation Distortion
0.004
％
Frequency Response
At rated output: 20 - 20,000Hz
＋
0,
－
0.2dB
At 1 watt output: 0.5 - 160,000Hz
＋
0,
－
3.0dB
Gain
28.0dB (with GAIN selector at MAX)
(in streo and monophonic operation)
Gain selectio n
MAX, -3dB, -6dB, -12dB
Output Load Impedance
Stereo operation: 2 to 16 ohms
Monophonic operation: 4 to 16 ohms
Damping Factor
200
Input Sensitivity
(with 8 ohm load,GAIN selector in MAX position)
Stereo operation 0.76 V for rated output
0.11 V for 1 watt output
Monophonic operation 1.51 V for rated output
0.11 V for 1 watt output
Input Impedance
Balanced: 40 kilohms Unbalanced: 20 kilohms
Signal-to-Noise Ratio (A-weighted,input shorted)
115 dB (GAIN selector in MAX position)
120 dB (GAIN selector in -12dB position)
At rated output
Output Level Meters
Logarithmic scale,with defeal switch,
and sensitivity switch(-20dB)- 50dB to
+3dB(indication dB and
％
)
Power Requirements
AC120V / 230V ,50/60Hz
(Voltage as indicated on rear panel)
Power Consumption
235 watts idle
430 watts in accordance with IEC 60065
Maximum di
mensions Width 465 mm (18-5/ 16")
Height 211 mm (8-5/16")
Depth 4 64 mm (18-1/ 4")
Weight
30.9 kg (68.1 lbs) net
38.0 kg (83.8 lbs) in shipping carton
全高調波ひずみ率
ｽﾃﾚｵ仕様時(両ﾁｬﾝﾈﾙ同時動作) 0.05％ 2Ω負荷
0.03％ 4～16Ω負荷
ﾓﾉﾌｫﾆｯｸ仕様時(ﾌﾞﾘｯｼﾞ接続) 0.05％ 4～16Ω負荷
IMひずみ率
0.004％
周波数特性
定格連続平均出力時：20～ 20,000Hz ＋0－0.2dB
1W出力時 ：0.5～160,000Hz＋0－3.0dB
ｹﾞｲﾝ(利得)
28.0dB (GAINｽｲｯﾁ:MAX時)
(ｽﾃﾚｵ/ﾓﾉﾌｫﾆｯｸ仕様時共)
ｹﾞｲﾝ切替
MAX,-3dB,-6dB,-12dB
負荷ｲﾝﾋﾟｰﾀﾞﾝｽ
ｽﾃﾚｵ仕様時 2～16Ω
ﾓﾉﾌｫﾆｯｸ仕様時 4～16Ω
ﾀﾞﾝﾋﾟﾝｸﾞ・ﾌｧｸﾀｰ
200
入力感度(8Ω負荷、
GAIN
ｽｲｯﾁ：
MAX
時)
ｽﾃﾚｵ仕様時 0.76V 定格連続平均出力時
0.11V 1W出力時
ﾓﾉﾌｫﾆｯｸ仕様時 1.51V 定格連続平均出力時
0.11V 1W出力時
入力ｲﾝﾋﾟｰﾀﾞﾝｽ
ﾊﾞﾗﾝｽ 40kΩ、ｱﾝﾊﾞﾗﾝｽ 20kΩ
S/N(A補正、入力ｼｮｰﾄ)
115dB GAINスイッチ MAX
120dB GAINスイッチ -12dB
定格連続平均出力時
出力ﾒｰﾀｰ
-50dB～+3dB(dB/％表示)
対数圧縮型、表示消灯機能付、
ﾒｰﾀｰ感度切替機能(-20dB)
電源
AC100V 50/60Hz
消費電力
235W 無入力時
430W 電気用品安全法
290W 8Ω負荷定格出力時
最大外形寸法
幅465mm×高さ211mm×奥行464mm
質量
30.9kg
定格連続平均出力(20～20,000Hz間)
注意：(※)印の負荷は、音楽信号に限る。
Continuous Average O utput Power (20
～
20,000Hz)
Stereo operation 360watts per channel into 1 ohm(
＊
)
(both channels driven) 180watts per channel into 2 ohms
90watts per channel into 4 ohms
45watts per channel into 8 ohms
Monophonic operation 720watts into 2 ohms(
＊
)
(bridged connection) 360watts into 4 ohms
180watts into 8ohms
Note: Load rating marked(
＊
)apply only to operation with
music signals.
ｽﾃﾚｵ仕様時 360W/ch 1Ω負荷(※)
(両ﾁｬﾝﾈﾙ同時動作) 180W/ch 2Ω負荷
90W/ch 4Ω負荷
45W/ch 8Ω負荷
ﾓﾉﾌｫﾆｯｸ仕様時 720W 2Ω負荷(※)
(ﾌﾞﾘｯｼﾞ接続) 360W 4Ω負荷
180W 8Ω負荷
861-3159-00
※音楽信号に限り、ｽﾃﾚｵ1Ωと
ﾓﾉﾌｫﾆｯｸ2Ω負荷可能
With music signals only, 1-ohm loads
are permissible for stereo operation and
2-ohm loads for monophonic operation.
