Accurex XBEW User Manual

Kitchen Hoods • Type I and Type II 3
Canopy Hood Weights
Example 1 • IMPERIAL
Hood Model XBEW Hood Weight Equation (lb)
Hood Length 120 inches (10 ft.) Constant (lb) + Hood Length (ft) x Hood Depth Factor (lbs/ft) = Hood Weight (lbs)
Hood Depth 60 inches (5 ft) 54 lbs + 10 ft x 27 lbs/ft = 324 lbs
Example 2 • METRIC
Hood Model XD2 Hood Weight Equation (kg)
Hood Length 42 inches (1.067 m) Constant (kg) + Hood Length (m) x Hood Depth Factor (kg/m) = Hood Weight (kg)
Hood Depth 36 inches (0.914 m) 42 kg + 1.067 m x 31 kg/m = 65 kg
XB - E - W
Filter
XB - Baffle Filter
XX - Grease-X-Tractor™
XG - Grease Grabber™
Make-Up Air Style
E - Exhaust Only
D - Exhaust Only - Double-Wall Front
Configuration
W - Wall Style Canopy
V - Single-Island Style (V-Bank) Canopy
P - Proximity (Backshelf)
Model Number Code
Hood Model
Hood Depth (Multiply Second Value by Length, then add First Value for Hood Weight)*
3 ft
.914 m
3.5 ft
1.067 m
4 ft
1.219 m
4.5 ft
1.372 m
5 ft
1.524 m
5.5 ft
1.676 m
6 ft
1.829 m
6.5 ft
1.981 m
7 ft
2.134 m
XBEW
34 lbs + 22 lbs/ft 38 lbs + 23 lbs/ft 42 lbs + 24 lbs/ft 46 lbs + 25 lbs/ft 50 lbs + 26 lbs/ft 54 lbs + 27 lbs/ft 58 lbs + 28 lbs/ft 63 lbs + 29 lbs/ft 67 lbs + 30 lbs/ft
51 kg + 33 kg/m 57 kg + 34 kg/m 63 kg + 36 kg/m 68 kg + 37 kg/m 74 kg + 39 kg/m 80 kg + 40 kg/m 86 kg + 42 kg/m 94 kg + 43 kg/m 100 kg + 45 kg/m
XXEW
34 lbs + 25 lbs/ft 38 lbs + 26 lbs/ft 42 lbs + 27 lbs/ft 46 lbs + 28 lbs/ft 50 lbs + 29 lbs/ft 51 lbs + 30 lbs/ft 55 lbs + 31 lbs/ft 59 lbs + 32 lbs/ft 64 lbs + 33 lbs/ft
51 kg + 37 kg/m 57 kg + 39 kg/m 63 kg + 40 kg/m 68 kg + 42 kg/m 74 kg + 43 kg/m 76 kg + 45 kg/m 82 kg + 46 kg/m 88 kg + 48 kg/m 95 kg + 49 kg/m
XGEW
34 lbs + 33 lbs/ft 38 lbs + 34 lbs/ft 42 lbs + 35 lbs/ft 46 lbs + 36 lbs/ft 50 lbs + 37 lbs/ft 51 lbs + 38 lbs/ft 55 lbs + 39 lbs/ft 59 lbs + 40 lbs/ft 64 lbs + 41 lbs/ft
51 kg + 49 kg/m 57 kg + 51 kg/m 63 kg + 52 kg/m 68 kg + 54 kg/m 74 kg + 55 kg/m 76 kg + 57 kg/m 82 kg + 58 kg/m 88 kg + 60 kg/m 95 kg + 61 kg/m
XBDW
34 lbs + 26 lbs/ft 38 lbs + 27 lbs/ft 42 lbs + 28 lbs/ft 46 lbs + 29 lbs/ft 50 lbs + 30 lbs/ft 51 lbs + 31 lbs/ft 55 lbs + 32 lbs/ft 59 lbs + 33 lbs/ft 64 lbs + 35 lbs/ft
51 kg + 39 kg/m 57 kg + 40 kg/m 63 kg + 42 kg/m 68 kg + 43 kg/m 74 kg + 45 kg/m 76 kg + 46 kg/m 82 kg + 48 kg/m 88 kg + 49 kg/m 95 kg + 52 kg/m
XXDW
34 lbs + 29 lbs/ft 38 lbs + 30 lbs/ft 42 lbs + 31 lbs/ft 46 lbs + 32 lbs/ft 50 lbs + 33 lbs/ft 51 lbs + 34 lbs/ft 55 lbs + 35 lbs/ft 59 lbs + 36 lbs/ft 64 lbs + 37 lbs/ft
51 kg + 43 kg/m 57 kg + 45 kg/m 63 kg + 46 kg/m 68 kg + 48 kg/m 74 kg + 49 kg/m 76 kg + 51 kg/m 82 kg + 52 kg/m 88 kg + 54 kg/m 95 kg + 55 kg/m
XGDW
34 lbs + 37 lbs/ft 38 lbs + 38 lbs/ft 42 lbs + 39 lbs/ft 46 lbs + 40 lbs/ft 50 lbs + 41 lbs/ft 51 lbs + 42 lbs/ft 55 lbs + 43 lbs/ft 59 lbs + 44 lbs/ft 64 lbs + 46 lbs/ft
51 kg + 55 kg/m 57 kg + 57 kg/m 63 kg + 58 kg/m 68 kg + 60 kg/m 74 kg + 61 kg/m 76 kg + 63 kg/m 82 kg + 64 kg/m 88 kg + 65 kg/m 95 kg + 68 kg/m
*Hood weight calculations are based on standard selection. Hood height, accessories and material gauge affect overall hood weight.
Hood Model
Hood Depth (Multiply Second Value by Length, then add First Value for Hood Weight)*
2 ft
.609 m
2.5 ft
.762 m
3 ft
.914 m
3.5 ft
1.067 m
4 ft
1.219 m
4.5 ft
1.372 m
5 ft
1.524 m
5.5 ft
1.676 m
6 ft
1.829 m
6.5 ft
1.981 m
7 ft
2.134 m
XBEV
37 lbs + 25 lbs/ft 41 lbs + 26 lbs/ft 45 lbs + 27 lbs/ft 49 lbs + 28 lbs/ft 53 lbs + 29 lbs/ft 57 lbs + 30 lbs/ft 61 lbs + 31 lbs/ft 66 lbs + 32 lbs/ft 70 lbs + 33 lbs/ft
55 kg + 37 kg/m 61 kg + 39 kg/m 67 kg + 40 kg/m 73 kg + 42 kg/m 79 kg + 43 kg/m 85 kg + 45 kg/m 91 kg + 46 kg/m 98 kg + 48 kg/m 104 kg + 49 kg/m
XXEV
37 lbs + 28 lbs/ft 41 lbs + 29 lbs/ft 45 lbs + 30 lbs/ft 49 lbs + 31 lbs/ft 53 lbs + 32 lbs/ft 57 lbs + 33 lbs/ft 61 lbs + 34 lbs/ft 66 lbs + 35 lbs/ft 70 lbs + 36 lbs/ft
55 kg + 42 kg/m 61 kg + 43 kg/m 67 kg + 45 kg/m 73 kg + 46 kg/m 79 kg + 48 kg/m 85 kg + 49 kg/m 91 kg + 51 kg/m 98 kg + 52 kg/m 104 kg + 54 kg/m
XGEV
37 lbs + 36 lbs/ft 41 lbs + 37 lbs/ft 45 lbs + 38 lbs/ft 49 lbs + 39 lbs/ft 53 lbs + 40 lbs/ft 57 lbs + 41 lbs/ft 61 lbs + 42 lbs/ft 66 lbs + 43 lbs/ft 70 lbs + 44 lbs/ft
55 kg + 54 kg/m 61 kg + 55 kg/m 67 kg + 57 kg/m 73 kg + 58 kg/m 79 kg + 60 kg/m 85 kg + 61 kg/m 91 kg + 63 kg/m 98 kg + 64 kg/m 104 kg + 65 kg/m
XO/XD1
16 lbs + 12 lbs/ft 20 lbs + 13 lbs/ft 24 lbs + 14 lbs/ft 28 lbs + 15 lbs/ft 32 lbs + 16 lbs/ft 36 lbs + 17 lbs/ft 40 lbs + 18 lbs/ft 44 lbs + 19 lbs/ft 48 lbs + 20 lbs/ft 53 lbs + 21 lbs/ft 57 lbs + 22 lbs/ft
XD2
24 lbs + 20 lbs/ft 28 lbs + 21 lbs/ft 32 lbs + 22 lbs/ft 36 lbs + 24 lbs/ft 40 lbs + 25 lbs/ft 44 lbs + 26 lbs/ft 48 lbs + 27 lbs/ft 52 lbs + 28 lbs/ft 57 lbs + 29 lbs/ft
36 kg + 30 kg/m 42 kg + 31 kg/m 48 kg + 33 kg/m 54 kg + 36 kg/m 60 kg + 37 kg/m 65 kg + 39 kg/m 71 kg + 40 kg/m 77 kg + 42 kg/m 85 kg + 43 kg/m
XD3
24 lbs + 22 lbs/ft 28 lbs + 23 lbs/ft 32 lbs + 24 lbs/ft 36 lbs + 29 lbs/ft 40 lbs + 30 lbs/ft 44 lbs + 31 lbs/ft 48 lbs + 32 lbs/ft 52 lbs + 33 lbs/ft 57 lbs + 34 lbs/ft
36 kg + 33 kg/m 42 kg + 34 kg/m 48 kg + 36 kg/m 54 kg + 43 kg/m 60 kg + 45 kg/m 65 kg + 46 kg/m 71 kg + 48 kg/m 77 kg + 49 kg/m 85 kg + 51 kg/m
