Replacement Parts
FILTERS
Part
Number
Filter Description
(Height x Width x Depth, in inches)
457627 16 x 16 x 2 Stainless Steel Baffle Filter
457629 16 x 20 x 2 Stainless Steel Baffle Filter
457633 20 x 16 x 2 Stainless Steel Baffle Filter
457635 20 x 20 x 2 Stainless Steel Baffle Filter
851709 16 x 16 x 2 Grease-X-Tractor™ SS Filter
851710 16 x 20 x 2 Grease-X-Tractor™ SS Filter
851712 20 x 16 x 2 Grease-X-Tractor™ SS Filter
851713 20 x 20 x 2 Grease-X-Tractor™ SS Filter
458763 16 x 16 x 2 Baffle Filter for Solid Fuel with Spark Arrestor
458764 16 x 20 x 2 Baffle Filter for Solid Fuel with Spark Arrestor
454878 20 x 16 x 2 Baffle Filter for Solid Fuel with Spark Arrestor
454879 20 x 20 x 2 Baffle Filter for Solid Fuel with Spark Arrestor
852881 16 x 16 Grease Grabber™ Second Stage Filter
852880 16 x 20 Grease Grabber™ Second Stage Filter
852879 20 x 16 Grease Grabber™ Second Stage Filter
852878 20 x 20 Grease Grabber™ Second Stage Filter
REGISTERS
Part
Number
Description
452700 24 x 8 Aluminum Single Deflection H-OB
452701 36 x 8 Aluminum Single Deflection H-OB
452702 36 x 8 Aluminum Single Deflection H-OB
452703 44 x 8 Aluminum Single Deflection H-OB
453796 24 x 12 Aluminum Single Deflection H-OB
453797 36 x 12 Aluminum Single Deflection H-OB
453798 38 x 12 Aluminum Single Deflection H-OB
453799 44 x 12 Aluminum Single Deflection H-OB
452729 24 x 8 Aluminum 38° Fixed Blade RA-OB
452730 30 x 8 Aluminum 38° Fixed Blade RA-OB
452731 36 x 8 Aluminum 38° Fixed Blade RA-OB
452732 38 x 8 Aluminum 38° Fixed Blade RA-OB
452733 44 x 8 Aluminum 38° Fixed Blade RA-OB
SWITCHES
Part
Number
Description
850551 Light Switch Only
851776 Fan Switch Only
851777 Light Switch & Fan Switch ( 2 switches)
851778 Fan Switch & Heat Switch (2 switches)
851779 Exhaust, Fan & Supply Switch (2 switches)
851780 Light, Fan & Heat Switch (3 switches)
851781 Light, Exhaust, Supply Separate Switch (3 switches)
851782 Exhaust, Supply, Heat Separate Switch (3 switches)
851783 Light, Exhaust, Supply, Heat Separate Switch (4 switches)
851784 Fan Switch & Temper (3 position) (2 switches)
851510 Light, Fans, & Temper (3 position) (3 switches)
851511 Exhaust, Supply, & Temper (3 position) (3 switches)
851512 Light, Exhaust, Supply, & Temper (3 position) (4 switches)
851618 Automatic Fire Damper Test Switch
MISCELLANEOUS
Part
Number
Description
451131 Grease Cup
453498 Glass Globe for hood lights (clear)
851744 Grease Extractor Filter Removal Tool
851834 Baffle Filter Removal Tool
483765 Hood 8-inch Round LED Light (LED-80-20DN)
385648 ASP 3.4-inch LED Light
384925 Hood Temp Sensor Only
484000 Hood Temp Sensor Compression Seal Only
