Accurex XBEW User Manual

Kitchen Hoods • Type I and Type II4
Supply Plenum - Weights and Dimensions
Proximity Hood Weights
External Supply
Plenum Type
Weight Width Height Length per section
lbs/ft kg/m in. mm in. mm ft. m
Air Curtain Supply (ASP)
Refer to Air Curtain
Supply Plenum
Weight Table
Refer Air Curtain
Supply Plenum
Weight Table
10 to 24 254.0 to 609.6 10 254.0 3 to 16 .91 to 4.88
Split Air Curtain Supply
(Split ASP)
12.5 18.64 24 609.6 10 254.0 3 to 16 .91 to 4.88
Back Supply (BSP) 35.0 52.09 6 152.4 Variable Variable 3 to 16 .91 to 4.88
Weight
Air Curtain Supply Plenum Width (inches)
10 11 12 13 14 15 16 17 18 19 20 21 22 23 24
lbs/ft 6.2 6.5 6.7 6.9 7.1 7.3 7.6 7.8 8.0 8.3 8.5 8.7 8.9 9.2 9.4
kg/m 9.26 9.60 9.93 10.27 10.60 10.94 11.27 11.61 11.94 12.28 12.61 12.95 13.28 13.62 13.95
Hood Model
Base Weight and Weight per Length based on Hood Depth
23 to 25 in.
.584 to .635 m
26 to 28 in.
.660 to .711 m
29 to 32 in.
.737 to .813 m
33 to 36 in.
.838 to .914 m
XB, XX, XGEP
Base Weight
28 lbs
12.70 kg
30 lbs
13.61 kg
31.5 lbs
14.29 kg
33.5 lbs
15.20 kg
Weight Per Length
20.4 lbs/ft
30.36 kg/m
21 lbs/ft
31.25 kg/m
21.6 lbs/ft
32.14 kg/m
22.2 lbs/ft
33.04 kg/m
*Hood weight calculations are based on standard selection. Hood height, accessories and material gauge affect overall hood weight.
Example 1 • IMPERIAL
Hood Model XBEP Hood Weight Equation (lb)
Hood Length 60 inches (5 ft) Base Weight (lbs) + [ Length (ft) x Weight per Length (lbs/ft) ] = Hood Weight (lbs)
Hood Depth 24 inches (2 ft) 28 lbs/ft + (5 ft x 20.4 lbs/ft) = 130 lbs
Example 2 • METRIC
Hood Model XXEP Hood Weight Equation (kg)
Hood Length 192 inches (4.877 m) Base Weight (kgs) + [ Length (m) x Weight per Length (kg/m) ] = Hood Weight (kg)
Hood Depth 33 inches (0.838 m) 15.20 kg + (4.877 m x 33.04 kg/m) = 176.336 kg
