Machine Maintenance 3-85
press down on all sides to secure the keyboard into place.
Figure 3-130. Keyboard
4. Close the LCD panel and turn the computer over so that the base is facing up.
5. Secure the keyboard with the two screws.
Figure 3-131. Keyboard Screws
Table 3-32. Screws
Step Screw Quantity Screw Type
Keyboard Assembly M2.5 × L6 2
