Acer Aspire 4560 - Main Unit Maintenance

Machine Maintenance 3-19
Main Unit Disassembly Process 0
Main Unit Disassembly Flowchart 0
Figure 3-21. Main Unit Disassembly Flowchart
Table 3-9. Screw List
Step Screw Quantity Acer Part Number
Keyboard Disassembly M2.5 × L6 2 86.00E12.536
Palmrest Module/Upper Cover Disassembly M2 × L3 3 86.00F80.723
M2.5 × L6 7 86.00E12.536
Speakers Disassembly M2 × L3 4 86.00F80.723
Power Button Board Disassembly M2 × L3 1 86.00F80.723
Mainboard Disassembly M2.5 × L6 1 86.00E12.536
Thermal Module Disassembly – 5
LCD Module Disassembly M2.5 × L6 4 86.00E12.536
KEYBOARD
BLUETOOTH
MODULE
THERMAL
MODULE
RTC
BATTERY
EXTERNAL MODULES
PALMREST MODULE/
UPPER COVER
POWER
BUTTON
BOARD
SPEAKER
MODULE
TOUCHPAD
BOARD
MAINBOARD
LCD
MODULE
USB
BOARD
CPU
