3-16 Machine Maintenance Procedures
USB Module Removal 0
Prerequisite:
Base Cover Removal
1. Disconnect USB module FFC (A) from USB module connector (B) (Figure 3-12).
2. Disconnect and remove USB module FFC (A) from mainboard connector
(C)(Figure 3-12).
Figure 3-12. USB module
B
A
C
