Acer Aspire V5-571 - Reinstalling the Battery Connector

Machine Maintenance 3-57
Reinstalling the Battery Connector 0
1. Place the battery connector into the lower case assembly.
Figure 3-80. Battery Connector
2. Secure the battery connector to the lower case assembly using two screws.
Figure 3-81. Battery Connector Screws
Table 3-81. Screws
Step Screw Quantity Screw Type
Battery Connector Reassembly M2 × L3 2
