1-32 Hardware Specifications and Configurations
LAN
Wireless LAN
Item Specification
LAN on Feature Port (thru
bundled Y Cable)
Realtek RTL8411 EN
LAN connector type RJ-45
LAN connector location Left
Features
10/100/1000BASE-T triple-speed MAC
Compliant with IEEE standards
Compliant with IEEE 802.3az draft standard for Energy
Efficient Ethernet™ (EEE)
ACPI-compliant Wake on LAN support
Item Specification
Module
Foxconn BCM 43228
Foxconn Atheros WB222
Lite-On Atheros WB222
Frequency band 2.4 GHz
Protocols and data
rates supported
802.11b – 1-11 Mbps
802.11g – 6-54 Mbps
802.11n – 6.5-300 Mbps
Interface PCI Express
Form factor Compact Half-Mini Card
Antennae Yes, two routed in the display assembly
