Acer P1165E - Page 21

P1165E&P5260E 16
Step Figure Description
6
Disconnect the connectors of
the fans, then pull off the fans
as the direction as the photo
showing.
7
Disconnect the wires then pull
the power module out.
Note: there is no screw for the
module.
FAN1
FAN2
Power module
B3
