USING THE PROJECTOR
Menu navigation and features
The projector has multilingual on-screen display menus that allow you to make image adjustments and change a
variety of settings. The projector will automatically detect the source.
1. To open the OSD menu, press the button on the projector keypad or the Menu button on the remote
control.
2. When OSD is displayed, use pq keys to select any item in the main menu. While making a selection
on a particular page, press the button on the projector keypad or the Enter button on the remote
control to enter sub menu.
3. Use tu keys to select the desired item in the sub menu and then press the or Enter button to
view further settings. Adjust the settings by using tu keys.
4. Select the next item to be adjusted in the sub menu and adjust as described above.
5. Press press the or Enter button to conrm, and the screen will return to the main menu.
6. To exit, press the or Menu button again. The OSD menu will close and the projector will
automatically save the new settings.
Sub Menu
Main Menu
Settings
Navigation guide
Image Settings
3D
Aspect Ratio
Edge Mask
Zoom
Image Shift
Keystone
Display
Select
Exit Enter

Acer PL6610T Specifications

General

Number of colors	1.073 billion colors
Native aspect ratio	16:10
Projection distance	1 - 9 m
Projection technology	DLP
Supported aspect ratios	4:3, 16:10, 16:9
Contrast ratio (typical)	2000000:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Vertical synchronization (max)	0.12 kHz
Vertical synchronization (min)	0.023 kHz
Keystone correction, horizontal	-30 - 30 °
Horizontal synchronization (max)	102 kHz
Horizontal synchronization (min)	15 kHz
Lamps quantity	1 lamp(s)
Light source type	Laser
Service life of light source	20000 h
Service life of light source (economic mode)	30000 h
Built-in display	No
Focus	-
Throw ratio	1.4 to 2.24 (1676.40 mm@2000 mm)
Zoom capability	Yes
Focal length range	20.91 - 32.62 mm
Aperture range (F-F)	2.5 - 3.26
Analog signal format system	NTSC, PAL, SECAM
Composite video in	1
Serial interface type	RJ-45
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	0
Noise level	- dB
Projection modes	Ceiling, Front, Rear
Compatible operating systems	Mac Windows
RMS rated power	10 W
Placement	Ceiling
Product type	Ceiling-mounted projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	120 - 230 V
Power consumption (standby)	- W
Power consumption (typical)	321 W
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 80 %
Harmonized System (HS) code	85286200

Weight and Dimensions

Weight	6000 g
