Acer X1130P User Manual

3
Revision List
Version
Release
Date
Revision History
Vendor
Model
Name
Rev0 2009.07.16
First Release
Rev0 2009.07.20
Modify FRU List—service lamp P/N
Rev0 2009.07.27
(P.5) Modify SPEC : Projection Offset = 120% ±5%
Rev1 2009.07.29
Add X1230PK different part :
(1) Ch1- SPEC,
(2) Ch3- Disassembly process, Module Assembly Key Point
(3) Ch4- alignment procedure
(4) Ch5-FRU List
(5) Appd. A- DDC table
Rev2 2009.09.11
Add X1130PA different part :
(1) Ch1- SPEC,
(2) Ch3- Disassembly process, Module Assembly Key Point
(3) Ch4- alignment procedure
(4) Ch5-FRU List
(5) Appd. A- DDC table
Rev3 2009.09.23
Add X1230P, X1230PA, X1237 different part
(1) Ch1-SPEC
(2) Ch2-“How Change Model Name” for X1230P/X1230PA/X1237
(3) Ch3- Disassembly process
(4) Ch4-Adjustment / Alignment Procedure
(5) Ch5-FRU List
(6) Appendix A-Remote Control Code
(7) Appd. A- DDC table

Acer X1130P Specifications

General

Number of colors	1.073 billion colors
Projection distance	11.3 m
Vertical scan range	50 - 85 Hz
Horizontal scan range	30 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	3000:1
Screen size compatibility	0.73 - 7.62 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	±40 °
Digital zoom	2 x
Aspect ratio	4:3, 16:9
RS-232 ports	1
Dimensions (WxDxH)	264 x 225 x 95 mm
Power requirements	100 - 240V
Lamp type	UHP
Lamp power	189 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
Serial interface type	RS-232
Noise level	31 dB
Power consumption (standby)	1 W
Power consumption (typical)	280 W

Weight and Dimensions

Weight	2300 g
