Acer X1160P - Projector Overview; Projector Outlook

3
English
Projector Overview
Projector Outlook
Front / upper side
Rear side
# Description # Description
1 Zoom ring (X1160Z/ZC/PZ/PZC, X1260/Z/
ZC/P/PZ/PZC/K/KC series)
5 Power button and Power Indicator LED
2 Focus ring 6 Remote control
3 Zoom lens 7 Remote control receivers
4 Lens cap
# Description # Description
1 PC analog signal/HDTV/component
video input connector
6
Kensington
TM
lock port
2 S-Video input connector
Below items are for X1260/Z/ZC/P/PZ/PZC/K/
KC series only:
3 Composite video input connector 7 RS232 connector
4 USB connector 8
Monitor loop-through output
connector (VGA-Out)
5 Power socket 9 Audio input connector
6
2
7
4
7
3
5
1
1237 89
5
6
4
