2) AUDIO ALARM SETUP
It is for the setup of audio alarm. For each input, it is possible to
turn on/off of the audio alarm.
STEP 1) Select the “AUDIO ALARM SETUP” from the ALARM SETUP Menu, and then press
[ENTER] .
STEP 2) When the AUDIO ALARM SETUP appears, select the input number to be changed with the
[Up/Down] button and then press [ENTER].
STEP 3)The “AUDIO Loss” of the desired input would change to Red, and with the [Up/Down]
button, select “ON” or “OFF”.
STEP 4) To change the Audio Max setup, move to the “AUDIO MAX” setup with the [Left/Right]
button. Then, the set value would change to Red, and select “ON” or “OFF” with the [Up/Down]
button and press [ENTER].
STEP 5) To apply the changed setup, select “APPLY” with the [Up/Down] button and exit of the
menu by pressing [EXIT]. To not apply the changed setup, press “CANCEL”.
1. In case of the input loss, it means the concurrent incurrence of video loss and audio loss.
Therefore, if either alarm for video loss or audio loss is turned off, there will be no input loss.
2. Intervals of video freeze and audio loss alarm can be set via NMS. The default values for
video freeze and audio loss are “20 seconds” and “60 seconds” respectively.
3. When all the alarms for the corresponding input are “OFF” (Video/Audio Loss, Video Freeze
and Audio Max Alarm), the boundary of the input of which the alarm is turned off is changed
to red to show that all the alarms are turned off. Refer to the [Figure 27]
