GB SPOT
15
6. CANCELLATION OF RADIO CONTROL CODES
It may become necessary to cancel all the radio command codes memorised, including the “MOTH-
ER” (in case of loss). To do so, press and hold down the external push button (in stop position) until
the central unit signals that the codes have been cancelled through three short consecutive UP and
DOWN cycles of the blind.
When the external push button is missing, the following procedure can be carried out by simulating
the putting on of the push button, through the connection of the red and black cable (low tension com-
mands, see paragraph 12).
Remember that in the subsequent memorising of new codes, the first radio command will be coded
and recognised by the central unit as the new “MOTHER”.
For the memorizing procedure of the “Mother” Remote Control, please follow the method indicated
in paragraph 9, or to invert the motor power supply cables (black and brown F.6)
7. INSTALLATION OF THE ANEMOMETER WINDY
If the wind is too strong it may damage the bearing structure of the blind or the blind itself. To
prevent that, the “SPOT” control unit has been prepared for installation of an anemometer.
The anemometer is installed near the blind, well exposed to the wind, and connected to the red and
white wires. For the electrical connections see fig. 6 paragraph 12.
The anemometer intervention threshold can be set for 2 speeds; 15 kph.
N.B. INTERVENTION BY THE ANEMOMETER INHIBITS OPERATION OF THE RADIO CONTROL
UNIT AND OF THE EXTERNAL PUSH BUTTON FOR ABOUT 8 MINUTES.
Warning! Verify that the intervention of the anemometer actually completes the closure run of the
awnings, if this were not the case, invert the direction (see paragraph 2).
8. PROGRAMMING THE ANEMOMETER’S TRIPPING SPEED
Using the Spot, you can set the tripping speed of the anemometer (15 km/h or 30 km/h) simply by us-
ing the "MOTHER" radio control.
Programming should be performed as follows:
1) Power the “Spot”;
2) Press and hold down both the keys on the “MOTHER” radio control until the gear motor (through
two brief awming movements, one upwards and the other downwards), displays entry into pro-
gramming mode;
3) Press any key on the “MOTHER” radio control; The gear motor will display the anemometer’s cur-
rent tripping speed setting as follows:
• a brief gear motor movements in each direction (opening/closing) 15 km/h
• 2 brief gear motor movements in each direction (opening/closing/opening/closing) 30 km/h
4)
At this point, if you wish to alter the tripping speed, press any button on the "MOTHER" radio control:
Each time the key is pressed, the gear motor will show the tripping speed setting (as described in point 3).
5) Once the desired speed is set, in order to exit programming mode, simply wait approximately 30
seconds without performing any operations.
N.B.! if the “mother” radio control is lost, in order to programme the tripping speed you will need to can-
cel the stored codes and re-programme the “mother” radio control (follow the instructions in paragraph 7).
9. INVERSION OF THE DIRECTION OF MOVEMENT
A need to reverse the direction of movement may arise, to ensure that the UP key actually makes the
blind move up. To invert the direction of rotation, press and hold down both keys of the “MOTHER”
radio control. The central unit signals entry into programming status by two brief movements of the
blind (one up and one down). At that point press the external push button (red/black). Inversion is sig-
nalled by the central unit by means of two brief movements of the blind, UP and DOWN.
10. WARNINGS FOR INSTALLATION
• The SPOT central control unit must be installed only by qualified personnel and used
only to operate tubular motor-reducers for sun or window roller blinds.
