5.4 Connect the medical device to the air system
Ask an approved dental installation technician to connect your medical device to the air system.
The air supply system pressure may vary throughout the day. The air supply system pressure must be adapted to the
values recommended for your medical device. It is very important to make sure that the maximum pressure permitted
for the medical device is never reached or exceeded. If in doubt, you are strongly advised to install or arrange for
installation of an air pressure limiting system.
The air supply system must comply with the quality criteria compatible with the practice of dental treatments.
5.5 Connecting the medical device to the air supply
The air filter and air pipe with CPC quick coupling are located on the back of the medical device. Connect the quick
coupling to the air supply inlet.
1. CPC quick air coupling
5.6 Connecting the medical device to the electrical network
Have your medical device connected to the mains power by an approved dental installation technician.
A different voltage would cause damage to the medical device and could injure the patient and the user. Any variation
in the electrical network voltage or electromagnetic field that is non-compliant with the limits in force, could interfere
with the medical device's operation.
Medical devices equipped with a protective earth must be connected to a supply network equipped with a protective
earth.
Do not plug the medical device into an extension lead and do not put the mains cord in a cable cover or cable
tray.
5.7 Connecting the medical device to the electrical network
1. Set the medical device's mains switch to "O" OFF position.
2. Connect the mains cord to the control unit's mains connector.
3. Connect the power lead to the mains socket.
Page 14/42 - User Manual|AIRMAX|J11401|V7|(03)|12/2017|ND07EN010G
