12 Technical specifications of the medical device
12.1 Identification
Manufacturer SATELEC, a company of Acteon group
Name of the medical device AIRMAX
12.2 Control unit
Width 300 mm
Height 110mm
Depth 250 mm
Weight 2,700 g
Ingress protection rating IPX0
12.3 Generator
Supply voltage (factory setting) 115VAC or 230VAC
Electric power supply frequency 50 Hz / 60 Hz
Insulation 4kV (1ms)
Power consumption 50 VA
Operating mode Intermittent: 10 minutes ON / 5 minutes OFF
Type of leakage currents LF
Electrical rating 1
Internal fuse not accessible to the user Ref FU1: 4AT / 125V
Fuse (mains connector)
Two 0.5 AT fuses for 230 V
Two 1 AT fuses for 115 V
12.4 Length of cords
Handpiece cord 2 500 mm +/- 50 mm
Control pedal cord 2 500 mm +/- 50 mm
12.5 Irrigation
Intake air pressure 5.1 to 6 bar (65 to 87 p.s.i.)
Water pressure at inlet 1 to 5 bar (15 to 72.5 p.s.i.)
Powder flow rate 1 to 4 g/min
Capacity of the powder container 50 g
12.6 Main performance characteristics
12.6.1 Polishing mode
l pressure/air flow
l pressure/water flow
l Acteon dental powder with a controlled grain size.
12.7 Environmental characteristics
Ambient operating temperature +10°C to +40°C
Operating RH 30% to 75%
Atmospheric operating pressure Between 800 hPa and 1060 hPa
User Manual|AIRMAX|J11401|V7|(03)|12/2017|ND07EN010G - Page 31/42
