DIAGNOSTIC
7.1. DIAGNOSTIC
With “x-mind ac” radiographic system it is possible to set and visualise certain functional parameters.
To visualise them proceed as follows:
1. press simultaneously and keep pressed the keys
(17) MAXILLA MOLAR
(47) MANDIBULARY MOLAR
2. press the key associated to the parameter one wishes to visualise
KEY DISPLAY PARAMETER
RADIOGRAPHIC SYSTEM
NOMINAL VOLTAGE
LINE VOLTAGE
MAXIMUM LINE VOLTAGE
VALUE DETECTED
MINIMUN LINE VOLTAGE
VALUE DETECTED
SOFTWARE VERSION
