Lateral view (open)
Bottom mount
B
40 cm (16’’) bracket 178 cm
80 cm (31’’) bracket 220 cm
110 cm (43’’) bracket 247 cm
The system can also be mounted with the timer on the top. For details, refer to the Installation and Maintenance
Manual.
MOBILE INSTALLATION
“x-mind ac” exists also in the mobile version and it is sustained by the stand shown in the following gure:
For details, refer to the Mobile Unit Technical Note, supplied with this structure.
