Hardware Manual
18
Step 4: Connect to Network
Connect the other end of the network cable to a switch or injector. Then, connect the switch or
injector to a network or PC and a power source. See Power-over-Ethernet (PoE) example
connection diagram below.
Network
AC Power
Source
PoE Injector /
PoE Switch
Power Cable
Ethernet Cable
Ethernet Cable
(Data + Power)
Ethernet Cable
(Data)
Camera
NOTE: When installing the camera outdoors, make sure to waterproof the cable
connection.
Step 5: Access the Camera Live View
See Accessing the Camera on page 26 for more information on how to access the Live View of
the camera.
