4. Align and attach the fixing bracket to one of the holes on the camera using the supplied
screw (holes marked below). The fixing bracket will fix the camera position when mounted
later.
5. Align and insert the camera base hooks to the mounting holes of the metal plate.
6. Slide the camera clockwise to secure the hooks to the mount.
