Hardware Manual
9
Physical Description
Z83 / Z84
Item
Description
1
DC 12V Power
Input
In case the camera is connected to a non-PoE (Power over
Ethernet) switch, use this connector to connect the camera to an
external power adapter (not included). See How to Connect a
Power Adapter (Optional) on page 21 for more information.
2
Ethernet Port
Connects to a network using an Ethernet cable with RJ-45
connector.
3
Reset Button
Restores the camera to its factory default settings. To reset the
camera, use a pin to press and hold the Reset Button for about
15 seconds.
4
Memory Card Slot
Insert a memory card into this slot for local recording purposes.
5
