Chapter 6 Advanced Setup
The beginning and ending IP addresses define the IP address range of the
Gateway. If the default values are left intact, the Gateway supplies a unique IP
address between 192.168.0.2 and 192.168.0.254 to each computer on the net-
work. Note that the first three groups of numbers of the addresses are identical;
this means they are on the same subnet. The IP address of the Gateway must
be on the same subnet as the IP address range it generates. For instance, if the
Gateway’s IP address is changed to 10.33.222.1, set the beginning IP address to
10.33.222.2, and the ending IP address to 10.33.222.254.
DNS (Dynamic or Static) - the type of DNS server provided by the
Internet Service Provider (ISP). If the ISP provided DNS server
information, select the type here. If not, leave as is.
DNS Server 1 - the primary DNS server provided by the Internet
Service Provider (ISP). If the ISP provided DNS server informa-
tion, enter it here. If not, leave the text box intact.
DNS Server 2 - the secondary DNS provided by the Internet Service
Provider (ISP). If the ISP provided secondary DNS server infor-
mation, enter it here. If not, leave the text box intact.
Services Blocking
Selecting Services Blocking in the “Advanced Configuration” screen generates the
“Services Blocking” screen.
To modify Internet privileges (Web, FTP, Newsgroups, etc.) for the computers on
the network:
1. Enter the computer’s IP address in the IP Address: text box.
2. Select the Internet service(s) to be blocked.
