85
Chapter 6 Advanced Setup
WAN - IP Address
Displays the IP Address the ISP assigned to the Gateway.
WAN - Subnet Mask
Displays the Subnet Mask address the ISP assigned to the Gateway.
WAN - Gateway
Displays the Gateway address (for the IP Address and Subnet Mask) the ISP
assigned to the Gateway.
WAN - DNS #1 & #2
Displays the Domain Name Server address(es) the ISP assigned to the Gateway.
LAN - IP Address
Displays the Local Area Network’s (LAN) IP address.
LAN - Net Mask
Displays the Subnet Mask address configured for the LAN IP address.
LAN - DHCP Server
Displays the state of the DHCP Server (On or Off).
In the left hand column, there are other Status options available: Routing Table,
WAN Status, LAN Status, and Active User List. Click to generate the option of
choice.
