Active Vision SX-420 User Guide
18
Provides simple On/Off switching by using relay. 0.5A/125V, 1A/30V
POWER
Connect AC115/230V power cable.
SWITCHES
TEST
For future use
422/485
Select 422 or 485
VGA
Set to ON when VGA monitor is used.
PAL
Set to ON when video is PAL
CAUTION: Once the position of the switch is changed, 9-16CH should be rebooted to apply the
new setting value.
