Active Vision SX-420 User Guide
26
REMOTE CONTROL ID
Select a ID of remote controller.
1. Select ID.
2. Press the same number as ID set in DVR on a remote
controller.
3. Then
icon will be displayed on Live screen of DVR that
respond to the remote controller.
3-4-1. ALARM-OUT
Table 3.4.2. Menu item in ALARM-OUT Setup screen
Item Description
ALARM OUT
Select alarm from 1 to 8.
SENSOR IN
Enable setting up to 4 sensors of 16 sensors.
MOTION ON
Enable setting up to 4 cameras of 16 cameras.
VIDEO LOSS ON
Enable setting up to 4 cameras of 16 cameras.
ALARM DURATION
Set the dwell time of alarm from1 to 60seconds.
SENSOR
Select sensor from 1 to 16.
TYPE
Set the type of sensor for the specified channel from none, N/O
(normal open), and N/C (normal closed).
