ActronAir LM7-D User Manual

13
ESP FAN FEATURE
Available for ESP Plus and ESP Ultima Models
CIRCULATION OPERATION
FAN SPEED CYCLE:
HIGH = High air circulation.
MED = Normal air circulation.
LOW = Low air circulation.
ESP = Variable air circulation, varying fan speed will be determined by the controller
automatically. This will depend on number of outlets or zones open in an installation.
CIRCULATION OPERATION
FAN SPEED CYCLE:
HIGH = High air circulation.
MED = Normal air circulation.
LOW = Low air circulation.
CONT HIGH = High air circulation, continuous run.
CONT MED = Normal air circulation, continuous run.
CONT LOW = Low air circulation, continuous run.
ESP = Variable air circulation, variable fan speed will be determined by the controller
automatically. This will depend on number of outlets or zones open in an installation.
CONT ESP = Continuous variable air circulation, varying fan speed will be determined by the
controller automatically. This will depend on number of outlets or zones open in an
installation.
WALL CONTROLLER DISPLAY
SPEED
SEGMENT INDICATOR
LCD DISPLAY
HIGH MED LOW
HIGH ON SET TEMP
MED ON SET TEMP
LOW ON SET TEMP
ESP ON ON ON ESP THEN SET TEMP
WALL CONTROLLER DISPLAY
SPEED
SEGMENT INDICATOR
LCD DISPLAY
HIGH MED LOW CONT
HIGH ON SET TEMP
MED ON SET TEMP
LOW ON SET TEMP
ESP ON ON ON ESP THEN SET TEMP
CONT HIGH ON ON SET TEMP
CONT MED ON ON SET TEMP
CONT LOW ON ON SET TEMP
CONT ESP ON ON ON ON ESP THEN SET TEMP
FAN CYCLE
LOW
ESP
HIGH
MED
LOW
CONT ESP
ESP
CONT
HIGH
CONT
MED
CONT
LOW
HIGH
MED
FAN CYCLE
