TROUBLESHOOTING
32
Error Messages (Keypad Test)
The messages below indicate that a problem was found during the key-
pad test at startup. If an error message appears, turn the system off,
press the appropriate key to release it back into position, and then
restart the system. (Or you can press the
CLEAR key to clear the error
message.) If the key does not work during normal operation, contact
your distributor for repair/replacement procedures.
SETUP key
E11
E12
MM key
E15
E16
X key
E18
E21
BOLT DEF key
E22
E25
7 key
E26
E28
C/L key
ABS/INCR key
9 key
8 key
ZERO key for the
X-axis
E31
6 key
E35
E36
E38
E41
E45
E46
E48
E51
E54
E55
E32
E56
BOLT USE key
5 key
4 key
1 Axis - X key
2 & 3 Axis - Y key
E33
CLEAR key
3 key
2 key
1 key
1 Axis - ZERO key (X)
2 & 3 Axis - ZERO key (Y)
± key
ENTER key
0 key
Decimal point (.) key
ZERO key for the Z-
axis
Z key
E57
E58
