100S Reference Manual

SETUP

There are five parameters that you can define on your system:

• Display resolution (diS)

• Linear error compensation (LEC)

• Scale resolutions (rES)

• Scale count directions (Ct dir)

• Position Recall (recall)

Establish each setting the first time you power up the system. You can

change the parameters later by returning to Setup and then using the

ENTER key to scroll to the appropriate category.

Anytime you change the linear error compensation, or count direction

for an axis, the absolute and incremental displays for that axis will be

reset to 0. If you change these settings, you will need to re-establish the

datum point.

When in the Setup mode, use the CLEAR key when you want to back-

space, restore the previous value or access the previous parameter.

Parameter Setup
