II – 1 Installation Setup
U In the Error Monitor field, select whether the system will monitor,
and display encoder errors by selecting ON, or OFF. When an error
message occurs, press the C key to remove it.
Display Configuration
The Display Configuration form is where the operator determines
which axes are displayed, and in what order.
U Scroll to the desired display and press ENTER.
U Press the ON/OFF soft keys to turn the display on, or off. Press the
RIGHT/LEFT arrow keys to select the axis label.
U Scroll to the Input field.
U Scroll to the Display Resolution field. Press the COARSER, or FINER
soft keys to select the display resolution.
U Scroll to the Angle Display field if the encoder type is set to Rotary.
Press the ANGLE soft key to display the position as 0° - 360°, ±
180°, ± infinity, or RPM.
Coupling
U Press the numeric keys associated with the encoder input on the
back of the unit. Press the + or - soft keys to couple a second input
with the first. The input numbers are displayed next to the axis label
indicating that the position is a coupled position (i.e. “2 + 3”).
The encoder resolution and count direction can also be
established by just moving each axis.
