664Y0200.C
1000 mm
1000 mm
2000 mm
2000 mm
fig. 7 : Chimney connectors type C xx
C43
C53
C13
C33
2 m min.
150 min.
120
C13
C13
fig. 8 :
Concentric connector
fig. 9 :
Parallel connector
Parallel connector
Table of maximum chimney pressure drop. 100 Pascal
(1 Pascal = 0.01 mbar)
SV - MV
Ø 80 mm
Pipe L. 500 mm 1.18
Pipe L. 1000 mm 2.55
Pipe L. 2000 mm 5.1
90° Bend 4.32
45° Bend 2.75
30° Bend 1.67
15° Bend 0.69
Vertical terminal 5.4
Horizontal terminal 5.5
Condensate trap 2.06
This table is based on material provided by ACV and cannot be generalised.
Exampleofcalculation:
The following diagram consists of
the following components (Ø 80 mm) :
•1x90°Bend
•2xPipeL2000mm
•2x45°Bend
•2xPipeL1000mm
•1xVerticalterminal
•1xCondensatetrap
Calculation:
•1x4,32 = 4,32
•2x5,1 = 10,2
•2x2,75 = 5,50
•2x2,55 = 5,10
•1x5,4 = 5,4
•1x2,06 = 2,06
Total: 32,58 x 2 = 65,16 Pa
As this value
is lower than
themaximum
permissible
resistance,
this installation
is compliant.
INSTALLATIoN
Inparallelconnection,ameasuringunitwithcondensate
trapmustbefitted.
Concentric connection
Maximumlength,concentric:6metresisduetothemaximum
permissibletemperatureof70°attheinletoftheventuri.
N.B.:
- A90°bendisequivalenttoapressuredropofonemetre.
Example:
- 6metres,concentric=190°bend+4horizontalmetres+
1terminalmetre.(Concentriccomponentseetariff.)
“CE”approvedaccordingtoEN483
A drain outlet must be provided near the boiler to
prevent condensation from the chimney entering the
boiler.
Allhorizontalpiperunsmustfalltotheboilertoprevent
condensationwaterescapingfromtheterminal.
