ACV alfa Sprint M User Manual

EN • 17
ENGLISHFRANCAISNEDERLANDSESpAñoLITALIANoDEuTSCH
664Y0200.C
SETTING PARAMETERS
GAS CATEGORIES
Type S SV M MV
Input
Kw
34.9 34.9 10 / 34.9 10 / 34.9
Nominal output
Kw
31.15 31.15 9.2 / 31.15 9.2 / 31.15
Combustion efficiency - natural gas
%
91 91 93.8 / 90.7 93.8 / 90.7
Offset
mbar
0 0 0 - 0.4
Starting speed
Rpm
- - 3600 4000
Min. speed
Rpm
- - 1600 1530
Max. speed
Rpm
4150 4940 4210 4940
CO2 natural gas
%
9 9 9 9
CO2 propane gas
%
11.0 - 11.2 11.0 - 11.2 11.0 - 11.2 11.0 - 11.2
GasG20-20mbar-I2E(S)B-I2Er-I2H-I2ELL-I2E
Flow
m
3
/h
3.70 3.70 1.06 / 3.70 1.06 / 3.70
GasG25-20mbar-I2ELL/25mbar-I2L
Flow
m
3
/h
4.30 4.30 1.23 / 4.30 1.23 / 4.30
GasG31-30/37/50mbar-I3P
Flow
m
3
/h
1.43 1.43 0.41 / 1.43 0.41 / 1.43
Burner chamber pressure
mbar
0.2 0.2 0.2 0.2
Net T° of combusted gases
°C
190 190 120 / 190 120 / 190
BE FR AT DK ES UK IT PT IE SE NL LU DE
I 2Er
I2E(S)B
I 2H
I 3P
I 2L
I 2ELL
I 2E
N.B.:
•Theburnersarepresetinourfactoryforusewithnaturalgas(equivalenttoG20)
•Settingandadjustmentofthe%ofCO2isstrictlyprohibitedinBelgium.I2E(S)BB
BuRNER CHARACTERISTICS
