DOMINO 24 & 48 USER MANUAL
www.adblighting.com
User Manual - page 51
Issue 1.2
15.5 SET A PATCH LEVEL
All patches can have a proportional patch level.
For example, if a patch level is set to 50%, setting a channel fader to 100% will turn on its
dimmer at 50%.
When editing the patch (above), select the DMX slot whose patch level you wish to change.
The LED in the [f/a] button of the channel patched to this slot will flash.
Hold down the [f/a] button and the display shows the patch level.
Whilst holding down the channels [f/a] button, rotate the EDIT wheel to set the patch level.
When finished patching, press [edit].
The patch is automatically saved.
15.6 UNPATCH A DMX SLOT FROM A CHANNEL
To delete a single patch, edit the patch (above) and select the DMX slot (above) then press
[remove].
The display scrolls, “Delete patch to DMX#?” Press [yes].
Alternately, select the DMX slot and set the proportional patch level to zero.
15.7 1 TO 1 PATCH
A 1 to 1 patch is available to speed the patching process. It directly connects each channel
number to its matching DMX slot number.
To add a “1 to 1 patch”; HOLD [function], tap [patch].Press [add], [yes].
Note: adding a 1 to 1 patch will replace any existing patches
