DOMINO 24 & 48 USER MANUAL
www.adblighting.com
User Manual - page 12
Issue 1.2
Note: In the event of a short loss of mains power (a “brown out”) the DOMINO will
continue to operate for a few seconds due to the storage capacity of its internal
power supply.
2.6 POWER SUPPLY RESET
In the unlikely event that your DOMINO does not shut down after the second click you can
force it to do so by momentarily pressing the power supply reset switch. Remove the power
then insert a small insulated pointer into the small hole above of the “VIDEO” connector.
2.7 FUSE
A 0.5 Amp slow blow fuse is located in a slide out tray beside the mains input socket.
Should the fuse blow, remove the mains lead and slide out the fuse tray. Pop out the blown
fuse and replace it with a 0.5 Amp slow blow fuse. A spare fuse is provided in the slide out
fuse tray. Replace the spare fuse if you use it.
2.8 AUDIO INPUT
The audio input is used for “Sound to Light” effects. See the “STL” section for details.
2.9 DESK LAMP
A goose-neck desk lamp may be connected to this socket. The socket provides both power
and mounting for the lamp. There is an internal self-resetting thermal fuse for the power to
the lamp.
2.10 USB
Upper USB connector for Flash Disk (Memory Stick); lower USB connector for Trackball
(only DOMINO 48 XT and DOMINO 96 XT).
